A passion project for our legendary R&D Chief Juergen Falke, the Warp Tri drew on many of the aero learnings from the Pro Tour TT bike using a superlight CF5 frame for ultimate performance but incorporated a lot of thinking about comfort and efficiency as Juergen a seasoned Ironman competitor was very aware of the demands of different courses and distances. The Vision Metron S-Bend cockpit allows for multiple position adjustments for a perfect riding position on any course as well as provide outstanding control on even the most demanding of sections.
Specification
| Frame | CF5 IV carbon - Premium fibres for lightweight and performance, Internal cable routing, 142 x12mm axle standard, flat mount rear brakes, Pressfit 86.5 BB Standard, Max tyre size - 30c |
|---|---|
| Fork | Time-Warp Tri CF5 IV; Full carbon, tapered steerer, Max tyre size: 700 x 30c |
| Headset | Meida TIME WARP TT |
| Shift Levers | Shimano ST-R9180 |
| Front Derailleur | Shimano Ultegra Di2; FD-R8150 |
| Rear Derailleur | Shimano Ultegra Di2; RD-R8150 |
| Speeds | 24 |
| Cassette | Shimano CS-R8101; 11-30 teeth; 12 speed |
| Chain | Shimano CN-M8100-12 |
| Chainset | Shimano Ultegra; 52-36 tooth chainset; Crank length - 170mm (XS), 172.5mm (S/M), 175mm (L) |
| Bottom Bracket | SM-BB72-41B, Pressfit 86.5 |
| Brake Type | Hydraulic disc |
| Brake Lever | Shimano Dura Ace |
| Front Brake | Shimano Dura Ace; Hydraulic disc brake caliper with Shimano CL900; 160mm rotor |
| Rear Brake | Shimano Dura Ace; Hydraulic disc brake caliper with Shimano CL900; 140mm rotor |
| Wheel Size | 700c |
| Rim | Part of wheelset - Vision TC55; 19mm inner rim width; 55mm rim depth; carbon; Tubeless ready (tubeless tape and valves not included) |
| Spokes | Part of wheelset |
| Front Hub | Part of wheelset - Vision TC55; 100 x 12mm; Centerlock |
| Rear Hub | Part of wheelset - Vision TC55; 142 x 12mm; Centerlock |
| Front Tyre | Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
| Rear Tyre | Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready |
| Stem | Merida Metron TT; carbon; -17 degree rise |
| Handlebar | Merida Metron TT; carbon |
| Grips | Merida Expert |
| Saddle | Prologo Zero Tri PAS Tirox |
| Seat Post | Merida Team TT II; Aero shape; Carbon |
Geometry
