Merida use triple butted 6066 series aluminium which is hydroformed to tune the frame for a comfortable, responsive ride. For versatility, the frame can accommodate wider tyres up to 35mm, or 32mm with mudguards.
The upright position, flat bars and powerful hydraulic disc brakes are ideal for commuting, providing greater control and an enhanced field of vision when riding through traffic.
Road.cc called it an 'excellent fast flat-bar road bike with awesome performance' and certified it to be a 'lovely bike – great fun, versatile, practical'.
Specification
| Frame | Lite III - 6066 triple butted hydroformed aluminium. Internal cable routing. Tapered head tube, inboard disc mount, BSA BB standard, 135 x 9mm QR axle. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 35c (700 x 32c with mudguard) |
|---|---|
| Fork | Merida Speeder Lite; material: aluminium; 700Cx35" max. tyre size |
| Headset | Merida M2331 Neck |
| Shift Levers | Rear: Shimano Essa SL-315-8R |
| Rear Derailleur | Shimano ESSA ; RD-U2000 |
| Speeds | 8 |
| Cassette | Shimano Essa HG 300; 11-45 teeth; 8 speed |
| Chain | KMC Z8 |
| Chainset | Shimano Essa; 40 tooth chainset; Crank length: 170mm |
| Bottom Bracket | Shimano UN101 LL123 |
| Brake Type | Hydraulic Disc |
| Front Brake | Shimano MT200; 2 piston with Shimano RT10; 160 mm |
| Rear Brake | Shimano MT200; 2 piston with Shimano RT10; 160 mm |
| Wheel Size | 700c |
| Rim | Merida Comp SL; 19mm inner rim width; 24mm rim depth; material: aluminium; Tubeless ready (tubeless tape and valves not included) |
| Spokes | Black stainless |
| Front Hub | Shimano TX505; 100x9mm; 32 Spoke; Centerlock |
| Rear Hub | Shimano TX505; 135x9mm; 32 Spoke; Centerlock |
| Front Tyre | Maxxis Detonator; 700x32C; wired |
| Rear Tyre | Maxxis Detonator; 700x32C; wired |
| Stem | Merida Comp CC; material: aluminium; 31.8 mm diameter; 7 degree rise |
| Handlebar | Merida Comp TK; material: aluminium; 600mm wide; Flat |
| Grips | Merida Comp EC |
| Saddle | Merida Comp SL |
| Seat Post | Merida Comp CC; 30.9mm diameter; 5mm layback; material: aluminium |
| Pedals | VP VPE-891 |
Geometry
