The Crossway is the perfect blend of comfort, enjoyment and all around practicality, suitable for leisure rides or commuting.
All disc brake models use the same lightweight aluminium frame with a steep, sloping top tube providing plenty of standover height.
For ultimate adaptability, the Crossway range can be equipped with mudguards, racks and kickstands.
Specification
| Frame | TFS II - 6061 double butted technoformed aluminium tubing with internal cable routing. Tapered head tube, inboard disc mounts, BSA BB standard, 135 x 9mm QR axle standard. Mounts for rack, mudguards and kickstand. Max tyre size 700 x 50c |
|---|---|
| Fork | Suntour NEX HLO; Coil; 63mm travel; Lockout. Max tyre size: 700 x 48c |
| Headset | Merida M2346 Neck |
| Shift Levers | Shimano Altus |
| Front Derailleur | Shimano M370 |
| Rear Derailleur | Shimano Alivio |
| Speeds | 27 |
| Cassette | Shimano HG200; 11-34 teeth; 9 speed |
| Chain | KMC M99 |
| Chainset | SAMOX, AF29-321SSS-P chainset. Crank length: 170mm (S), 175mm (M,L) |
| Bottom Bracket | FSA TH-7420ST, Cartridge Bearing |
| Brake Type | Hydraulic disc |
| Brake Lever | Tektro HD-M275 |
| Front Brake | Tektro HD-M275 2 piston hydraulic disc brake caliper with Shimano RT10 160 mm rotor |
| Rear Brake | Tektro HD-M275 2 piston hydraulic disc brake caliper with Shimano RT10 160mm rotor |
| Wheel Size | 700c |
| Rim | Merida Comp TK; 20mm inner rim width; 17mm depth; Aluminium |
| Spokes | Black stainless |
| Front Hub | Shimano TX505; 100x9mm; 32 spokes; Center lock |
| Rear Hub | Shimano TX505; 135x9mm; 32 spokes; Center lock |
| Front Tyre | Maxxis Overdrive Excel; 700 x 40C; wire bead; reflective stripe, Silkshield |
| Rear Tyre | Maxxis Overdrive Excel; 700 x 40C; wire bead; reflective stripe, Silkshield |
| Stem | Merida Comp TK; aluminium; 31.8mm diameter; adjustable - Stem length: 80mm (XXS/XS/S), 90mm (M/L), 100mm (XL) |
| Handlebar | Merida Comp CC; aluminium; 660mm wide; 25mm rise |
| Grips | Merida Expert EC |
| Saddle | Merida Cross Sport |
| Seat Post | Merida TK; 30.9mm diameter; 10mm lay back; 40mm suspension travel |
| Pedals | VP Components, VPE-891 |
Geometry
