Mountain biking is one of the most varied cycling disciplines and probably the most demanding when it comes to equipment. While full suspension bikes offer amazing riding characteristics, the classic hardtail remains one of the purest tools for the job.
Specification
| Frame | CF3 III - carbon; Boost axle standard, BSA BB standard, Max. tyre size 29" x 2.4" |
|---|---|
| Fork | RockShox Judy Gold; Air; 100mm travel; Tapered; Remote lockout; 51 mm fork offset |
| Headset | Acros ICR Merida integrated neck; Upper and lower IPS sealing |
| Shift Levers | Shimano Deore M6100 |
| Rear Derailleur | Shimano Deore M6100; SGS |
| Cassette | Shimano Deore M6100; 10-51 teeth; 12 speed |
| Chain | KMC X13 |
| Chainset | Shimano Deore MT512; 32 tooth chainset with 170mm (S), 175mm M and above |
| Bottom Bracket | Shimano BB-MT-501; 24mm |
| Brake Type | Hydraulic disc |
| Brake Lever | Shimano MT200 |
| Front Brake | Shimano MT200; 2 piston hydraulic disc brake with Shimano RT-10 180mm rotor |
| Rear Brake | Shimano MT200; 2 piston hydraulic disc brake with Shimano RT-10 180mm rotor |
| Rim | Merida Expert CC II; 25mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included) |
| Spokes | Black stainless |
| Front Hub | Shimano HB-TC500-B; 100 x 15mm; 32 Spokes; Centerlock |
| Rear Hub | Shimano TC500-MS-B; 148 x 12mm; 32 Spokes; Centerlock with Merida Expert TR axle; including removeable lever, 6/4mm allen key |
| Front Tyre | Maxxis Rekon Race; 29 x 2.25"; wire bead |
| Rear Tyre | Maxxis Rekon Race; 29 x 2.25"; wire bead |
| Stem | Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 60mm (S/M); 70mm (L/XL), 80mm (XXL) |
| Handlebar | Merida Expert CC; aluminium; 760mm wide; flat |
| Grips | Merida Expert EC |
| Saddle | Merida Comp SL; V-mount |
| Seat Post | Merida Comp CC; aluminium; 30.9mm diameter; in-line |
Please be aware that images and descriptions are usually supplied by the brand / manufacturer and are in no way affiliated with Cycle Centre Congleton Limited T/A CycleStore. We only resell items from third parties and do not design or manufacture any products. Product information is compiled automatically from supplier data and occasional errors can occur — if a detail such as size, specification or price looks incorrect, please contact us to confirm before ordering.
