Merida's heartland has always been bombproof aluminium hardtails. Half a century of frame building experience counts for a lot.
All Big Nine and Big Seven models use a sophisticated TFS frame featuring the latest technology:
full internal cable routing for a clean, neat set up,
tapered headtube offering the potential for future upgrades
inboard disc brake mounts protect the brake and maximise stopping power
As much Shimano componentry as possible has been added to complement the modern frame and enhance reliability.
There are a wide range of sizes; Big Nine for taller riders and Big Seven for shorter riders with a healthy overlap between the two.
For riders in the middle, riding style can be taken into account. If you are looking for speed and efficiency choose a Big Nine, if you are looking for agility choose a Big Seven.
Specification
| Frame | TFS IV - 6061 aluminium, double butted and technoformed. Tapered head tube. Chain stay mounted disc brake. Internal cable routing. Mudguard and kick stand mounts. BSA threaded BB. 135mm x 9mm axle. Max. tyre size 29" x 2.25" |
|---|---|
| Fork | SR Suntour XCT30; Coil; 100mm travel; Max tyre size 29" x 2.25" |
| Headset | Merida M2345 |
| Shift Levers | Shimano FH-TY505 |
| Front Derailleur | Shimano FD-M315-TS |
| Rear Derailleur | Shimano RD-M302-8; SGS |
| Speeds | 16 |
| Cassette | Sunrace CSM558AU; 11-32 teeth; 8 speed |
| Chain | KMC Z8.3 |
| Chainset | Shimano FC-M315-2; 36-22 tooth chainset; Aluminium; Crank length - 170mm (S), 175mm (M and up) |
| Bottom Bracket | FSA TH-7420ST, 68-124 |
| Brake Type | Hydraulic disc |
| Brake Lever | Shimano EF505 |
| Front Brake | Shimano ST-EF505; hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Rear Brake | Shimano ST-EF505; hydraulic disc brake caliper with Shimano RT10; 160mm rotor |
| Wheel Size | 29" |
| Rim | Merida CC; 17mm inner rim width; aluminium |
| Spokes | Black steel |
| Front Hub | Shimano TX505; 100 x 9mm; 32 spoke; Centerlock |
| Rear Hub | Shimano TX505; 135 x 9mm; 32 spoke; Centerlock |
| Front Tyre | Merida K1080; 29" x 2.2"; wire bead |
| Rear Tyre | Merida K1080; 29" x 2.2"; wire bead |
| Stem | Merida CC; aluminium; 31.8mm diameter; 6 degree rise - Length - 70mm (S), 80mm (M), 90mm (L), 100mm (XL), 110mm (XXL) |
| Handlebar | Merida CC; aluminium; 690mm wide; 15mm rise |
| Grips | Merida EC |
| Saddle | Merida Sport comfort |
| Seat Post | Merida CC; 30.9mm diameter; 15 mm layback; Aluminium |
| Pedals | VP VPE-891 |
Geometry
