Our entry-level One-Sixty keeps the price low but the performance high, because we use suspension from legendary brand Marzocchi, super grippy rubber from Continental and Shimano's durable Deore drivetrain. Add in our progressive geometry, the option of mixed 29/27.5" or full 29" wheels and award winning FAST kinematic suspension and you can race, rip and rally any enduro trail you fancy, even if you're not flush with cash.
Specification
| Frame | Lite III Aluminium, Next Generation enduro geometry, internal cable routing, long seat post insert depth. Boost axles standard, threaded BB, trail mount and bottle bosses, flip chip for mullet or 29er. max tyre size - 2.5" |
|---|---|
| Rear Shock | Marzocchi Bomber inline; lockout |
| Fork | Marzocchi Z1; Air; 170 mm travel; Tapered; 44mm fork offset; 29x2.6" max. tyre size |
| Headset | Acros ICR Merida External neck; Upper and lower IPS sealing |
| Shift Levers | Rear: Shimano CUES U6000 |
| Rear Derailleur | Shimano CUES U6000; GS |
| Speeds | 11 |
| Cassette | SunRace 10-50t ZX11; CS-UX700 EA5; 10-50 teeth; 11 speed; Linkglide |
| Chain | KMC xGlide |
| Chainset | Merida Expert TR II; 32 tooth chainset; Crank length: 165mm |
| Bottom Bracket | Samox BSA 24mm EB2401 |
| Brake Type | Hydraulic Disc |
| Front Brake | SRAM DB4; 4 piston with SRAM CenterLine; 200mm |
| Rear Brake | SRAM DB4; 4 piston with SRAM CenterLine; 200mm |
| Wheel Size | 29" / 27.5" |
| Rim | Merida Comp TR II; 28mm inner rim width; material: aluminium; Tubeless ready (Stans 30mm tubeless tape installed and valves not included); rear 27.5" up to Size M / L & XL rear 29" |
| Spokes | Double Butted Black stainless w/black nipples |
| Front Hub | Shimano TC500-B; 110x15mm; 32 Spoke; Centerlock |
| Rear Hub | Shimano TC500-HM-B; 148x12mm; 32 Spoke; Centerlock |
| Front Tyre | Maxxis Minion DHF; 29x2.5"; EXO wired; tubeless ready |
| Rear Tyre | Maxxis Dissector; (XShort-Mid) - 27.5x2.4", (Long-XLong) - 29x2.4"; EXO wired; tubeless ready |
| Stem | Merida Comp TR; material: aluminium; 35 mm diameter; 0 degree rise; Length: 40mm |
| Handlebar | Merida Comp TR II; material: aluminium; 780mm wide; 35mm rise |
| Grips | Merida Comp TR |
| Saddle | Merida Comp SL; 25% recycled material; V-mount |
| Seat Post | Merida Expert TR II; 34.9mm diameter; in-line; (XShort-Short) - 150mm, Mid - 170mm, Long - 200mm, XLong - 230mm seat post travel |
| Pedals | Not included |
Please be aware that images and descriptions are usually supplied by the brand / manufacturer and are in no way affiliated with Cycle Centre Congleton Limited T/A CycleStore. We only resell items from third parties and do not design or manufacture any products. Product information is compiled automatically from supplier data and occasional errors can occur — if a detail such as size, specification or price looks incorrect, please contact us to confirm before ordering.
